The Hyundai HX48AZ is a compact hydraulic excavator equipped with a low-emission Tier 4 Final compliant diesel engine. It offers efficient operation and increased power in confined spaces. The HX48AZ received the prestigious 2022 Red Dot Design Award, recognizing outstanding industrial designs worldwide, along with the HX35AZ and HX40A. The excavators were honored, in part, for their distinctive “tiger eye” rear light design, showcasing a perfect blend of form and function.
504-464-0431
HX48AZ
Net Power
37.7 hp @ 2,200 rpm
Operating Weight
11199
Standard Bucket
0.2 yd³
Overview
Performance
Performance
KUBOTA TIER 4 FINAL ENGINE
The HX48AZ features Yanmar 4TNV88C diesel engine with a vertical, water-cooled 4-cycle direct injector. It has a net power rating of 37.7 HP (28.1 kW).
AUXILIARY HYDRAULIC FLOW
Auxiliary hydraulic flow is adjustable through the 5-inch LCD cluster.
ANGLE DOZER BLADE FLOATING
Blade height is automatically adjusted by turning on dozer blade float function.
ZERO-TAIL SWING
The HA48AZ has a compact design and swings within the width of the tracks which allows for safe swing and maneuverability in tight spaces.
Reliability
RELIABILITY & DURABILITY
Reliability
Hyundai construction equipment is precision designed with trusted and proven components and systems from leading OEM’s. The HX48AZ is designed to be rugged and reliable for longer up time, reduced operating cost and improved productivity.
Durability
Hyundai construction equipment is manufactured with the highest grade of steel due to Hyundai’s dominance in the steel and shipbuilding industries. Rigid cycle testing, heat testing, vibration testing and shock load testing is conducted in the design and manufacturing process of all new models insuring optimum durability and reliability.
Convenience
Convenience
5-INCH FULL-COLOR LCD MONITOR
The Hyundai HX48AZ features a 5-inch full-color LCD monitor with IP68 rating, providing operators with clear and comprehensive information for efficient machine control and monitoring during operations.
HEATING AND A/C SYSTEM
The HX-A mini excavators comes equipped with an integrated heating & air-conditioning system, providing a comfortable working environment inside the cabin in all climate conditions.
ERGONOMIC CONTROLS & SWITCHES
The left and right control levers are ergonomically located for convenient access. Pilot operated hand levers are easily accessible for controlling the dozer blade. Easy-to-access control switches on the left side console improve operating comfort and productivity.
CAB ENTRY
A tiltable left-side console allows the operator easier access to the cab. A safety lock system is designed to prevent exiting the cab while hydraulic controls are live. When the safety lever and left side console are positioned upright, hydraulic functions are disengaged.
Serviceability
Serviceability
Hi MATE TELEMATICS
Hyundai Hi MATE telematics now available on all HX-A series mini excavators for a 5-year standard subscription.
COWL DESIGN IMPROVEMENT
Cowling on the HX-A series has been completely redesigned so all panels are openable.
Safety
Safety
AUTO-SAFETY LOCK
If the operator accidentally releases the safety lever while the RCV lever is engaged, our excavator’s safety system prevents unintended operation. This ensures that the excavator is not controlled by the RCV lever and prevents potential accidents.
LED LIGHTING
The HX-A series is equipped standard with an LED boom light.
EXCELLENT VISIBILITY
Hyundai engineers updated the cab designs to provide more space, a wider field of vision and more operator comfort.
Optional Rearview Camera
The HX48AZ comes with the option of adding a rearview camera for increased safety and visibility on the jobsite.
Specifications
| Engine Model | Yanmar 4TNV88C |
|---|---|
| Net Power | 37.7 hp @ 2,200 rpm |
| Operating Weight | 11199 lb. |
| Bucket Capacity | 0.2 yd³ |
| Max Travel Speed | 2.7 mph |
| Swing Speed | 101 mph |
| Max. Digging Depth | 11' 10.5" |
| Max. Digging Reach | 10' 0.6" |
| Tail Swing Radius | 3' 6.5" |
| Bucket Breakout Force (Iso) | 7341 lb. |
| Arm Crowd Force (Iso) | 4998 lb. |
| Configuration: Compact, Crawler, Wheeled, Speciality | Compact |
