The high-performance of the LH 35 M Industry is demonstrated through its handling capabilities in every kind of application. The strong axles, which are very well suited for pulling logging trailers, enhance the working spectrum of this machine. The attachment of the machine is available in a variety of versions and is thus always optimally matched to your respective application.
504-464-0431
LH 35 M Industry Litronic
Operating Weight
67700
Overview
Specifications
| Operating Weight | 67700 lb. |
|---|---|
| Generation | 6 |
| Engine Output(ISO 9249) | 140 kW / 190 hp – 140 kW / 188 hp (SAEJ1349) |
| Emission Stage | Tier 4f |
| Avg. Consumption (per operating hour) | 3.46 gal/h |
| Configuration: Compact, Crawler, Wheeled, Speciality | Wheeled |
| Maximum Reach | 49' 3'' ft in |
| Grapple Capacity | 1.20 – 2.27 yd² (wood grab size) |
| Multi-tine grab capacity | 0.52 – 0.78 yd³ |
| Shells for loose material capacity | 1.57 – 3.27 yd³ |
| Sorting grab capacity | 0.98 – 1.50 yd³ |
