LH 60 M High Rise Litronic

Overview

The LH 60 M High Rise Industry is predestined not only for heavy duty material handling in the area of scrap and timber but also in harbour-related operations. The material handling machine is equipped with the patented Liebherr ERC System (energy recovery system), that gives the machine a boost in terms of performance and also saves fuel. This results in significantly greater material handling performance as well as improved machine economy. The attachment of the machine is available in a variety of versions and is thus always optimally matched to your respective application.

Specifications

Operating Weight 148400 lb.
Generation 6
Engine Output(ISO 9249) 190 kW / 258 HP – 190 kW / 255 hp (SAEJ1349)
Emission Stage Tier 4f
Avg. Consumption (per operating hour) 4.84 gal/h
Configuration: Compact, Crawler, Wheeled, Speciality Wheeled
Maximum Reach 65' 7'' ft in
Multi-tine grab capacity 1.44 – 2.22 yd³
Shells for loose material capacity 2.00 – 10.46 yd³
